Designed to clean solder paste deposits, fluxes and other residues in the production of PCBs
A co-solvent cleaning blend with excellent cleaning capacity and a very low environmental impact.
Topklean EL20A has been specially formulated to remove all types of baked-on flux residues and contaminants (fingerprints, dust, etc) left on printed circuit board assemblies or semiconductor modules.
Topklean EL20A is designed for use in a co-solvent process to remove residues and leave the surface free of organic and inorganic deposits, recommended for use in conjunction with ProSolv®IPA.
The low viscosity and low surface tension of ProSolv®IPA combined with
Topklean EL20A allows highly efficient cleaning of small components, high density PCB’s or boards populated with very low stand-off components.
Topklean EL20A has a low environmental impact, emissions are very low at operating temperatures. It does not harm the ozone layer and is easily biodegradable. Can be recycled by vacuum distillation without affecting composition and properties.
RECOMMENDED PROCESSES
Application:
Can be sprayed or dipped with ultrasonics.
Co-solvent or Bi-solvent Process:
Components immersed in Topklean EL20A and then in a second stage of ProSolv®IPA as a separate step.
- High Solvency Power – Most effective for cleaning soldering fluxes and processing residues.
- Effective degreaser in standard processes.
- Most effective when used in a co-solvent or bi-solvent process with ProSolv® IPA .
- Versatility – Can be tailored to end-user preferred working parameters.
- Can be used as a spray or immersion cleaner.
- Can be used with or without ultrasonics.
- Suitable for co-solvent or bi-solvent processes.
- Relatively Fast Drying – Facilitates quicker cleaning processes.
- Low Viscosity – Enhances ease of application.
- High soil loading capacity allows longer bath usage.
- Zero Ozone Depletion Potential (ODP)
- Low Global Warming Potential (GWP).
- Very low emission
- Can be sprayed or dipped with ultrasonics
- For the removal of fluxes, soldering residues, natural oils and greases.
- Please consult product Safety Data Sheet for further information.
ProSolv®AS-1 is available in the following container sizes and weights:
- 180 litre (approx.) drum, 250kg.
- 18 litre (approx.) can, 25kg.
The weight of ProSolv®AS-1 is 1.39 kg per litre.
SHELF LIFE
36 months from the date of manufacture.
Store in tightly closed original container in a well-ventilated place. Store at ambient temperatures and out of direct sunlight.
Customer service and technical support provided from qualified distributors worldwide. We can supply Safety Data Sheets, independent laboratory reports, product samples and further assistance. For more information or advice please contact us by telephone on +44 (0) 20 8281 6370 or use our contact form.
All vapour degreasing solvents are supplied and supported by EnviroTech Europe Ltd. Manufactured in the United Kingdom and available on short delivery times through our dedicated team of distributors worldwide.
